CE approved DC 24v stepper motor RS485 electric laboratory industrial reagent injection dosing OEM syringe pumps

Name: CE approved DC 24v stepper motor RS485 electric laboratory industrial reagent injection dosing OEM syringe pumps
Brand: Huiyu
Price: 800.00 USD

Buy cheap CE approved DC 24v stepper motor RS485 electric laboratory industrial reagent injection dosing OEM syringe pumps product

Warranty : 1 year

Customized support : OEM

Brand Name : Huiyu

Model Number : MSP60-1A

Place of Origin : Beijing, China

Application : Food and Beverage Industry, Pharmaceutical industry, wastewater treatment

Horsepower : 0.04

Power Source : Electric

Pressure : 0.1mpa

Structure : syringe pump

Cable Length : 1mm

Outlet Size : 1.5mm

Voltage : 24v

Power : 40w

motor : stepper motor

Name : medical reagent OEM syringe pumps

Stroke length : 6000 steps (60mm)

Single stroke operating time : 1.2--1200s

Compatible Syringe : 50ul,100ul,250ul,500ul,1ml,2.5ml,5ml,10ml,25ml

Valve type : two position three way electromagnetic valve

Turn time : ≤100ms

Max pressure : 0.1MPa

Dimensions : 114mmx45mmx254mm

Weight : 2KG

Certification : ce

Packaging Details : syringe pumps
carton with foam plastic

Port : Beijing,Tianjin,Qingdao

Supply Ability : 100 Set/Sets per Week

Price : $800.00/sets >=1 sets

Contact Now

Product Description

industrial reagent injection dosing OEM syringe pumps

CE approved DC 24v stepper motor RS485 electric laboratory industrial reagent injection dosing OEM syringe pumps

Technical parameter
Precision: ≤5‰
Stroke length: 6000 steps (60mm)
Control precision: 1 step (0.01mm)
Speed: 0.05-50mm/s
single stroke operating time:1.2--1200s
Compatible Syringe: 50ul,100ul,250ul,500ul,1ml,2.5ml,5ml,10ml,25ml
Valve type: two position three way electromagnetic valve
Turn time: ≤100ms
Max pressure: 0.1MPa
Fluid Path: borosilicate glass, PTEF, PEEK
Valve fitting: 1/4″-28UNF inner thread interface
Output signal: three OC gate
Communication interface: RS232/485 options
The rate of communication: 9600/38400bps options
Set up pump address: through 16 digit dial switch
Dimensions : 114mm×45mm×254mm
Power: 24V DC/1.5A
Operating condition: Temperature 15 to 40℃(the temperature effect syringe much)
Relative humidity :80%
Weight: 2KG

Optional accessories
Syringe
Tubing
Power adapter

Programmable Capabilities: Ramps, cutoff velocity, backlash compensation, syringe speeds, loops, terminate moves and delays, error detection, valve rotation selection, enhanced “h” factor capabilities including valve rotation CW and CCW

Technical parameters

Syringe pump	Power supply		Working temperature	Max current	Relative humidity	Dimension(mm)	Weight
MSP60-1A	24VDC		10-40℃	≤1.5A	80%	114×45×254	2kg

CE approved DC 24v stepper motor RS485 electric laboratory industrial reagent injection dosing OEM syringe pumps

OEM option

CE approved DC 24v stepper motor RS485 electric laboratory industrial reagent injection dosing OEM syringe pumps

CE certificate

CE approved DC 24v stepper motor RS485 electric laboratory industrial reagent injection dosing OEM syringe pumps
